Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Product Categories
Shenzhen Recoda technologies Limited
Contact Now

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Brand Name : RECODA

Model Number : CM03

Certification : CE / FC / ROHS

Place of Origin : China

MOQ : 1

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 5000 pcs/month

Delivery Time : 3-5 days after receiving your payment

Packaging Details : one pcs per box, fifty pcs per carton

Type : Reverse Camera

Images Sensors : SONY CCD

TV System : PAL/NTSC

Lens Angle(Deg.) : 90~120

Lens : 2.8/3.6/6.0mm optional

Ip rating : IP68

Effective Pixels : 512 x 582 pixels / 512 x 492 pixels

Resolution : 420TVL/480TVL/600TVL/700TVL optional

Dimensions : 83 (L) × 60 (w) × 55 (H) mm

N. G : 250g

Power Supply(DCV) : 12V DC

Warranty : 12 Months

Car Make : Truck,bus,trailer,tracktor......

Price : negotiation

Contact Now

Sony CCD 700 TVL Metal housing Side wide / front view Car Reversing Camera:

Main Features:

Model CM03
Type Reae View / Side View Camera
Sensor 1/3 SONY CCD
Resolution 420TVL/480TVL/600TVL/700TVL optional
Lens 2.8/3.6/6.0mm optional
Infrared LED light 9 PCS
IR Distance 10 m
Waterproof Rate IP68
View angle 120°
Dimensions 83 (L) × 60 (w) × 55 (H) mm
N. G 250g

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Specifications:

1. TV System: PAL/ NTSC
2. Effective Pixels: 512 x 582 pixels / 512 x 492 pixels
3. Sensing Area: 3.6mm x 2.7mm
4. Scanning System: 2: 1Interlace
5. Horizontal Sync. Frequency: 15.625 kHz / 15.734kHz
6. Vertical Sync. Frequency: 50Hz / 60Hz
7. Minimum Illumination: 0Lux (Infrared lamps on) 0.1Lux(day) / F1.2
8. Video Output: with BNC and 4 pin connector optional
9. S/N Ratio: Better than 48dB

10. Electronic Shutter: 1/60(NTSC) / 1/50(PAL) ~ 1/10, 000 Seconds

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Product's Pictures:

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Dimension Diagram:

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

Packageing:

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking WaterproofSony CCD 700 TVL Car Reversing Camera IP68 Black Parking WaterproofSony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof

CM03 Packing List

Number

Parts name

Count

Remarks

1

CM03 Camera

1

2

self-tapping screw

4

4

Expansion of plastic pipe

4


Product Tags:

car reverse camera



auto reversing camera


Quality Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof wholesale

Sony CCD 700 TVL Car Reversing Camera IP68 Black Parking Waterproof Images
